Wall Mounted Motorised Height Adjustable Workbench 6300LA-CT


Mini cabinet on wheels
Mini cabinet on wheels with drawer and inner drawer, fully extendable with soft-close pcs

Your configuration

Workbench module 6300LA-CT, width 79 cm
Installation Wall
Front height 40 mm
Height adjustment

Motorised, steplessly adjustable 300 mm (700-1000 mm excl. top board)

Speed level 30 mm/sec.
Operation Control button, Mini

The safety strip is placed under the front edge of the worktop. If anything touches the safety strip, the lifting unit stops

Electrical connection Plug for 230 V, max 5.0 A
Lifting force 100 kg
IP-class IP 20
Delivery modules

Ready-mounted worktop incl. safety switch, motors

Frame depth 576 - 606 mm from wall (Incl. front)

Cover panels for covering installations under the worktop:
12 mm white melamine. Several colours can be offered upon request.
White lacquered aluminum. Several colours can be offered upon request.
Top board:
30 mm worktop in high pressure laminate. Post-shaped front edge. Several colours can be offered upon request.

Plumbing connections Connection is made with flexible hoses
Dimensions cover plates

2 pcs, width = width of the lift -10 mm, height 438 mm,
thickness 12-20 mm

Width worktop Width = width of the lift
Depth worktop 565-630 mm (15 mm shallower than worktops on fixed cabinets)
Space to wall / adjoining cabinet 5 mm
Space to wall (for tiles) 15 mm
Tiling From 700 mm above floor (alternatively all the way down to the floor)
Fittings supplied Bracket for fronts
Warranty 2 years Warranty
This product is covered by a 2-year warranty against manufacturing defects.
